Continuous Casting and Extrusion Line for Aluminum Grain Refiner

Continuous Casting and Extrusion Line for Aluminum Grain Refiner
7CCE1
7CCE2
7photobank
7CCE3
7CCE4
7铝偲 铝钛硼
Product description
Parameters

Model

CCE400

CCE500

Dia. of Casting Wheel(mm)

1200

1400

Rotation Speed of Casting Machine(rpm)

2.5~3.7

1.6~2.3

Section Area of Casted Bar(mm2)

730

1000

Casted Bar Speed(m/min)

8.5~12.7

7.2~10.2

Wheel Dia.(mm)

400

500

Main Shaft Speed(rpm)

12.5

10

Main Motor Power(kW)

250

400

Product Dia.(mm)

8~12

8~15

Output(kg/h)

700

900
