Copper Bus Bar/ Rod/Profiles Continuous Extrusion line

Copper Bus Bar/ Rod/Profiles Continuous Extrusion line
22400铜排
22铜棒 铜排 铜型材
增加产品图片
Product description
Parameters

Model

TLJ350

TLJ400

TLJ500

TLJ550

TLJ630

Wheel Dia.(mm)

350

400

500

550

630

Main Motor Power(kW)

160

250

355

450

600

Copper Feedstock Dia.(mm)

16

20

25

27

30

Max. Width of Bus Bar(mm)

100

170

240

280

320

Dia. of Copper Rod(mm)

4.5~50

8~90

12~100

12~100

12~120

Product Section Area(mm2)

15~1000

75~2000

300~3200

300~4500

600~6400

Output(kg/h)

780

1200

1800

2000

2800
