Copper Bus Bar/ Strip Blank Continuous Extrusion line

Copper Bus Bar/ Strip Blank Continuous Extrusion line
TLI630
33Copper-Coils-New-2
33copper-strip
Product description
Parameters

Model

TLJ400U

TLJ500U

TLJ630U

Wheel Dia.(mm)

 400

500

630

Main Motor Power(kW)

250

315

600

Products Type

Bus Bar

Bus Bar

Strip Blank

Copper Feedstock Dia.(mm)

20

20

30

Max. Width of Products(mm)

220

320

420

Product Section Area(mm2)

75~2000

300~4500

——

Max. Width of Strip blank(mm)

——

——

14~18

Output(kg/h)

1200

1200

2800
