ACS Wire/ Cable Aluminum Sheath Continuous Cladding/Sheath line

ACS Wire/ Cable Aluminum Sheath Continuous Cladding/Sheath line
6DSC032876
6P10105189
6SLB350 6铝包钢丝
6acs61
6BTLY-36
6OPGW3
6同轴电缆6
Product description
Parameters

Model

SLB350

SLB400

SSLB500

Wheel Dia.(mm)

350

400

2×500

Products Type

ACS/Al. Sheath

ACS/Al. Sheath

HV Power Cable

Main Motor Power(kW)

200/160

250/315

600

Aluminum Feedstock Dia.(mm)

2×9.5

2×9.5/2×12

4×15

Core Dia.(mm)

4~8

4~8

50~150

Al. Thickness(mm)

0.35~1/0.6~3

0.35~1/0.6~3

2~4

Outer Dia.(mm)

6~30

12~50

60~180

Product Speed(m/min)

180/60

180/60

18
