Continuous Extrusion Production Line for Copper Flat Wire, Round Wire, and Other Shaped Wire
Product description
Parameters
|
Model |
TLJ3OO | TLJ300H |
|
Extrusion Wheel Diarneter(mm) |
300 |
300 |
| Main Motor Power(kw) |
90 |
110 |
|
Rod Diameter(mm) |
12.5 |
12.5 |
| Maximum Width of Flat Wire(mm) |
40 |
30 |
|
Minimum Diameter of Round Wire(mm) |
2.6 |
2.6 |
| Flat Wire Cross-Sectional Area(mm2) |
5-200 |
5-150 |
|
Output(kg/h) |
480 |
800 |
